| Technical Specifications |
| Alloy Steel Work Spindle Hardened & Ground Diameter |
80 |
100 |
110 |
125 |
| Morse Taper Number |
5 |
6 |
6 |
6 |
| Max. Longitudinal Movement of working Spindle(Z-Axis) |
510 |
510 |
510 |
600 |
| No. of Spindle Speeds |
9 |
9 |
9 |
9 |
| Range of Spindle Speeds-R.P.M |
20to300 |
15to250 |
15to250 |
15to250 |
| Longitudinal Work Spindle Feeds Nos. |
9 |
9 |
9 |
9 |
| Max. Height of Spindle Axis from Table Surface(Y- Axis) |
925 |
1000 |
1100 |
1250 |
| Min. Height of the Spindle Axis from Table Surface |
25 |
35 |
35 |
35 |
| Dimensions of the rotary table |
900*1105 |
1030*1375 |
1100*1450 |
1225*1675 |
| Longitudinal Table Traverse(W-Axis) |
1625 |
1775 |
1925 |
2050 |
| Long Table Travel Feeds(including one rapid) |
10 |
10 |
10 |
15 |
| Transversal Table Travel Feeds |
10 |
10 |
10 |
15 |
| Vertical Head Stoke Travel feeds |
4 |
4 |
4 |
15 |
| Rotary Table Automatic feeds |
10 |
10 |
10 |
15 |
| Max. Cross Movement of the table(X-Axis) |
1000 |
1100 |
1300 |
1550 |
| Max. Distance b/w Stay Bearing & Facing Head |
2400 |
2690 |
2800 |
2950 |
| Facing Head Diameter |
505 |
555 |
600 |
650 |
| Weight Approx in Kgs.(without packing & accessories |
8500 |
10000 |
11000 |
16500 |
