Hydraulic Press Brake

Description

Technical Specifications
Model	Tonnage	Table Length	Bending	Capacity	Table Width	Clear Pass	Ram Stroke	Open Height	Throat Depth	Approach Pressing Return Speed	Power	Packing Dimensions
HPS 215	20	1500	1.6*1500	2*1250	125	1050	100	250	100	35-9-35	3	1700×1050×1900
HPS 320	30	2000	2*2000	3*1250	125	1050	100	250	200	30-7-40	3	200×1150×1900
HPS 420	40	2000	2.5*2000	3*1500	180	1550	100	250	200	40-6-45	5	2200×1150×1800
HPS 425	40	2500	2*2500	3*1500	180	2050	100	250	200	40-6-45	5	2700×1150×1900
HPS 430	40	3000	1.6*3000	3*1500	180	2550	100	250	200	40-6-45	5	3200×150×2000
HPS 515	50	1500	4*1500	5*1250	180	1050	100	250	200	35-6-45	5	1700×1150×1900
HPS 520	50	2000	3*2000	4*1500	180	1550	100	250	200	35-6-45	5	2200×1150×1900
HPS 525	50	2500	2.5*2500	3*2000	180	2050	100	250	200	35-6-45	5	2700×1150×1900
HPS 530	50	3000	2*3000	2.5*2500	180	2550	100	250	200	35-6-45	5	3200×1150×2000
HPS 540	50	4000	1.6*4000	2*3000	180	3100	100	250	200	35-6-45	5	4200×1250×2300
HPS 625	65	2500	3*2500	4*2000	180	2050	150	330	200	35-6-45	5	2700×1200×2000
HPS 630	65	3000	2.5*3000	3*2500	180	2550	150	330	200	35-6-45	5	3200×1200×2000
HPS 640	65	4000	2*4000	2.5*3000	180	3100	150	330	200	35-6-45	5	4200×1250×2400
HPS 820	80	2000	5*2000	6*1500	180	5100	150	330	200	40-6-45	7.5	2200×1550×2100
HPS 825	80	2500	4*2500	5*2000	180	2050	150	330	200	40-6-45	7.5	2700×1550×2300
HPS 830	80	3000	3*3000	4*2500	180	2550	150	330	200	40-6-45	7.5	3250×1550×2300
HPS 840	80	4000	2.5*5000	3*3000	180	3100	150	330	200	40-6-45	7.5	4250×1650×2500
HPS 850	80	5000	1.6*6000	2.5*4000	180	4100	150	330	200	40-6-45	7.5	5300×1650×2700
HPS 860	80	6000	5*2500	2*5000	180	5100	150	330	200	40-6-45	7.5	6300×1750×2800
HPS 1025	100	2500	4*3000	1.6*6000	180	2050	150	330	200	40-6-45	10	2700×1550×2300
HPS 1030	100	3000	3*4000	5*2500	180	2550	150	330	200	40-6-45	10	3250×1550×2300
HPS 1040	100	4000	3*4000	4*3000	180	3100	150	330	200	40-6-45	10	4250×1650×2500
HPS 1050	100	5000	2.5*5000	3*4000	180	4100	150	330	200	40-6-45	10	5300×1700×2800
HPS 1060	100	6000	2*6000	2.5*5000	180	5100	150	330	200	40-6-45	10	6300×1750×2900
HPS 1225	125	2500	6*2500	8*2000	230	2050	150	350	300	40-6-45	15	2750×1650×2700
HPS 1230	125	3000	5*3000	6*2500	230	2550	150	350	300	40-6-45	15	3250×1650×2500
HPS 1240	125	4000	4*3500	5*3000	230	3100	150	350	300	40-6-45	15	4250×1650×2600
HPS 1250	125	5000	3*5000	4*4000	230	4100	150	350	300	40-6-45	15	5300×1750×2900
