Big Bore Lathe Machine

Description

Specification	10 ft	10 ft	12 ft	12 ft	12 ft	14 ft	14 ft	14 ft	16 ft	16 ft	16 ft	20 ft
Width of Bed	20″	22″	20″	22″	24″	20″	22″	24″	20″	22″	24″	24″
Centre Height	18″	20″	18″	20″	22″	18″	20″	22″	18″	20″	22″	22″
Width in Front of Face Plate	14″	12″	15″	15″	15″	15″	15″	18″	18″	18″	18″	20″
Swing in Gap Dia	52″	56″	52″	58″	62″	52″	58″	62″	52″	58″	62″	62″
Maximum Swing Over Carriage	26″	30″	26″	30″	32″	26″	28″	32″	26″	28″	32″	32″
Admit Between Centres	66″	60″	84″	84″	82″	108″	108″	105″	132″	130″	126″	174″
Spindle Hollow	4⅛”	4⅛”	4⅛”	4⅛”	4⅛”	4⅛”	4⅛”	4⅛”	4⅛”	4⅛”	4⅛”	4⅛”
Morse Taper of Centre	5	5	5	5	5	5	5	5	5	5	5	5
Range of Spindle Speed	60/400	50/350	50/350	50/350	25/300	50/350	50/350	25/300	55/400	50/350	25/300	25/300
